Remote Viewer™ — Fixed Sight Tech Specs

Industrial High Quality Camera
Image Resolution5 MP 2592×1944, 3 MP 2048×1536, 1.3 MP 1296×976
Sensitivity0.3 Lux colour, 0 Lux in IR mode with optional IR illuminator
InferredAutomatic Day/Night IR filter
Boxed CameraFixed 4 mm lens (90-degree viewing angle)
Optional LensIndustry standard CS-Mount (C-Mount compatible, additional optional lens are available, zoom and wide angle)
Operation Temperature-40 C (with no heater) to + 50 C
Satellite Communications Option
Uplink Speed9.6 Kbps
Downlink Speed9.6 Kbps
Satellite TypeLEO satellite, global coverage
AntennaBuilt in omni antennas
Transmittal Frequency1610 – 1626.5 MHz
Receive Frequency2483.5 – 2500 MHz
CoverageWordlwide**
Cellular Communications Option
Uplink SpeedLTE (variable)
Downlink SpeedLTE (variable)
Satellite Typen/a
AntennaBuilt in omni antennas
Environmental
Operating Temperature40°F to +122°F (-40°C to +50°C)
Relative Humidity5% to 95% (under 104°F/40°C)
ESD15kV
Shock and VibrationSAE J1455
GPS Capabilities
Accuracy<2.5m CEP 50%
Acquisition<3 secs hot start, <30 secs cold start
Receiver50 channels (WAAS, EGNOS, MSAS)
Sensitivity-162 dBm Tracking, Reacquisition
DefencesAnti-jamming technology
Certifications
ApprovalsFCC, Indsutry Canada
CoverageNorth America
Power Supply
Input voltage12 Volts nominal, 8 to 15 VDC
Power UsageTypically less than 2Ah per day with 24 images per day
Physical Specifications
SizeRemote Connect 7.5" x 7.375" x 3.25" (19 x 8.3 cms)
Camera Housing 19" x 10" x 6" (48.26 x 25.4 x 15.24 cms)
Control Panel 12" x 10" x 6" (30.48 x 25.4 x 15.25 cms)
Weight34 lbs (15.42 kgs)
OPERATIONAL COVERAGE
Geographic CoverageNorth America
